$799.99
|
Model
|
IBC-1000L
|
IBC-1200L
|
IBC-1500L
|
IBC-500L Vertical type
|
IBC-500L Horizontal type
|
|
Structure
|
All steel type
|
||||
|
Nominal/Full mouth capacity (L)
|
1000
|
1200
|
1500
|
500
|
500
|
|
Approved weight (kg)
|
130±2kg
|
115±2kg
|
128±2kg
|
65±2kg
|
65±2kg
|
|
Stacking weight (kg)
|
3900
|
3900
|
3900
|
1600
|
3900
|
|
Maximum allowable weight (kg)
|
1650
|
1650
|
1650
|
900
|
1650
|
|
Maximum allowable density (g/cm^3)
|
1.5
|
||||
|
Length
|
1000±5
|
1000±5
|
1000±5
|
1000±5
|
1000±5
|
|
Width
|
1200±5
|
1200±5
|
1200±5
|
600±5
|
1200±5
|
|
Height
|
1150±5
|
1350±5
|
1650±5
|
1150±5
|
700±5
|
|
Pallet height
|
120±5
|
120±5
|
120±5
|
120±5
|
120±5
|
|
Center distance of fork hole
|
795±5
|
795±5
|
795±5
|
795±5
|
795±5
|
|
Fork height
|
80±5
|
80±5
|
80±5
|
80±5
|
80±5
|
|
Appearance
|
Gray
|
||||
|
Interior container
|
|||||
|
Material
|
SUS304
|
||||
|
Manufacturing method
|
Forging and welding forming
|
||||
|
Inner container weight (kg)
|
65±1
|
79±1
|
98±1
|
42.5±1
|
42±1
|
|
Top thread type
|
/
|
||||
|
Filling diameter (mm)
|
DN150
|
||||
|
Top cap
|
|||||
|
Size
|
DN150 atmospheric pressure handhole
|
||||
|
Material
|
SUS304
|
||||
|
Gasket material
|
Tetrafluorowasher
|
||||
|
Air release valve
|
DN20 stainless steel exhaust valve
|
||||
|
Drain valve
|
|||||
|
Material
|
SUS304
|
||||
|
Gasket material
|
Tetrafluorowasher
|
||||
|
Inside diameter of outlet thread
|
56.5
|
||||
|
Tray
|
|||||
|
Material
|
Galvanize
|
||||
|
Processing method
|
Stamping
|
||||
|
Frame
|
|||||
|
Material
|
Galvanize
|
||||
|
Processing method
|
Steel pipe welding, bending after forming assembly
|
||||
